| 型式 | 最高使用壓力 kgf/cm?2 |
最大流量 l/min |
壓力調(diào)整範圍 kgf/cm?2 |
重量 kg |
||
|---|---|---|---|---|---|---|
| 配管式 | 板式 | |||||
| HT-03-※ | HG-03-※ | 250 | 50 |
A :?18-35
B :?35-70 C :?70-140 |
4.2 | 4.4 |
| HT-06-※ | HG-06-※ | 125 | 7.3 | 6.5 | ||
| HT-10-※ | HG-10-※ | 250 | 12.8 | 11.3 | ||
JGH壓力控制閥常規(guī)型號參考:HG-03-A-1 , HG-03-A-2 , HG-03-A-3 , HG-03-A-4 , HG-03-B-1 , HG-03-B-2 , HG-03-B-3 , HG-03-B-4 , HG-03-C-1 , HG-03-C-2 , HG-03-C-3 , HG-03-C-4 , HG-06-A-1 , HG-06-A-2 , HG-06-A-3 , HG-06-A-4 , HG-06-B-1 , HG-06-B-2 , HG-06-B-3 , HG-06-B-4 , HG-06-C-1 , HG-06-C-2 , HG-06-C-3 , HG-06-C-4 , HG-10-A-1 , HG-10-A-2 , HG-10-A-3 , HG-10-A-4 , HG-10-B-1 , HG-10-B-2 , HG-10-B-3 , HG-10-B-4 , HG-10-C-1 , HG-10-C-2 , HG-10-C-3 , HG-10-C-4 , HT-03-A-1 , HT-03-A-2 , HT-03-A-3 , HT-03-A-4 , HT-03-B-1 , HT-03-B-2 , HT-03-B-3 , HT-03-B-4 , HT-03-C-1 , HT-03-C-2 , HT-03-C-3 , HT-03-C-4 , HT-06-A-1 , HT-06-A-2 , HT-06-A-3 , HT-06-A-4 , HT-06-B-1 , HT-06-B-2 , HT-06-B-3 , HT-06-B-4 , HT-06-C-1 , HT-06-C-2 , HT-06-C-3 , HT-06-C-4 , HT-10-A-1 , HT-10-A-2 , HT-10-A-3 , HT-10-A-4 , HT-10-B-1 , HT-10-B-2 , HT-10-B-3 , HT-10-B-4 , HT-10-C-1 , HT-10-C-2 , HT-10-C-3 , HT-10-C-4
